Hyundai HG260
Model HG260 · Engine 6LTA8.9-C260
260 HP
Power
17.000 kg
Operating Wt.
1150 Nm
Torque
Informasi Umum
- Merek
- Hyundai
- Model
- HG260
- Kategori
- Motor Grader
Mesin
- Engine Brand
- Cummins
- Engine Type
- 6LTA8.9-C260
- Silinder
- 6
- Displacement
- 8900 cc
- Power
- 194 kW
- Power
- 260 HP
- Torque
- 1150 Nm
- Rated RPM
- 2200 rpm
- Turbocharged
- Ya
- Emission Standard
- EPA Tier 2 / EU Stage II
Berat & Kapasitas
- Operating Weight
- 17000 kg
- Shipping Weight
- 16500 kg
- Ground Pressure
- —
Sistem Hidrolik
- Pump Type
- Gear Pump / Piston Pump System
- Flow Rate
- 132 L/min
- System Pressure
- 17,5 MPa
- Hydraulic Tank
- 65 L
- Total Hydraulic System
- 150 L
Mobilitas
- Low Speed Travel
- 6,5 km/h
- High Speed Travel
- 49,2 km/h
- Gradeability
- 40 %
- Min Turning Radius
- 7900 mm
Dimensi
- Length
- 9240 mm
- Width
- 2620 mm
- Height
- 3630 mm
- Ground Clearance
- 430 mm
- Track Width
- 2150 mm
- Tail Swing Radius
- —
Kapasitas Fluida
- Fuel Tank
- 370 L
- Engine Oil
- 27 L
- Coolant
- 40 L
- Hydraulic Tank
- 65 L
- Hydraulic System
- 150 L
- Transmission Oil
- 28 L
Fast Moving Spare Parts
- Engine Oil Filter
- LF9009
- Fuel Filter
- FS19732 (Fuel/Water Separator) & FF5485 (Fuel Filter)
- Air Filter (Outer)
- AH1101 / YA00010041
- Air Filter (Inner)
- YA00010042
- Hydraulic Return Filter
- 31E1-0018 / 31Q4-20340
- Hydraulic Pilot Filter
- 31E1-0020
- Fan Belt
- 3911589
- Battery
- 12V / 120 Ah x 2 unit (Sistem 24V)
