Dynapac CC3800
Model CC3800 · Engine Cummins QSB3.3
99 HP
Power
9.400 kg
Operating Wt.
415 Nm
Torque
Informasi Umum
- Merek
- Dynapac
- Model
- CC3800
- Kategori
- Vibratory Roller
Mesin
- Engine Brand
- Cummins
- Engine Type
- Cummins QSB3.3
- Silinder
- 4
- Displacement
- 3300 cc
- Power
- 74 kW
- Power
- 99 HP
- Torque
- 415 Nm
- Rated RPM
- 2200 rpm
- Turbocharged
- Ya
- Emission Standard
- Tier 3 / Stage IIIA Equivalent
Berat & Kapasitas
- Operating Weight
- 9400 kg
- Shipping Weight
- 8900 kg
- Ground Pressure
- 27,6 kPa
Sistem Hidrolik
- Pump Type
- Variable displacement axial piston pump (Sistem sirkuit hidrostatis tertutup untuk travel drive dan sistem vibrasi dual drum)
- Flow Rate
- 115 L/min
- System Pressure
- 35 MPa
- Hydraulic Tank
- 52 L
- Total Hydraulic System
- 78 L
Mobilitas
- Low Speed Travel
- 3 km/h
- High Speed Travel
- 12 km/h
- Gradeability
- 38 %
- Min Turning Radius
- 4650 mm
Dimensi
- Length
- 4490 mm
- Width
- 1850 mm
- Height
- 2990 mm
- Ground Clearance
- 310 mm
- Track Width
- 1680 mm
- Tail Swing Radius
- 1150 mm
Kapasitas Fluida
- Fuel Tank
- 130 L
- Engine Oil
- 8,5 L
- Coolant
- 15 L
- Hydraulic Tank
- 52 L
- Hydraulic System
- 78 L
- Transmission Oil
- 1,5 L
Fast Moving Spare Parts
- Engine Oil Filter
- LF16011
- Fuel Filter
- FS19608 (Primary Fuel/Water Separator) / FF5631 (Secondary Filter)
- Air Filter (Outer)
- 382241
- Air Filter (Inner)
- 382242
- Hydraulic Return Filter
- 364731
- Hydraulic Pilot Filter
- 372023
- Fan Belt
- 395018
- Battery
- 1 x 12V / 100 Ah (Sistem kelistrikan elektrikal utama menggunakan sirkuit 12V)
