Caterpillar (CAT) D6 GC
Model D6 GC · Engine Cat C7.1
212 HP
Power
21.630 kg
Operating Wt.
980 Nm
Torque
Informasi Umum
- Merek
- Caterpillar (CAT)
- Model
- D6 GC
- Kategori
- Buldozer
Mesin
- Engine Brand
- Caterpillar
- Engine Type
- Cat C7.1
- Silinder
- 6
- Displacement
- 7010 cc
- Power
- 158 kW
- Power
- 212 HP
- Torque
- 980 Nm
- Rated RPM
- 2200 rpm
- Turbocharged
- Ya
- Emission Standard
- China Nonroad Stage III / Brazil MAR-1 Equivalent
Berat & Kapasitas
- Operating Weight
- 21630 kg
- Shipping Weight
- 18800 kg
- Ground Pressure
- 62 kPa
Sistem Hidrolik
- Pump Type
- Variable displacement piston pump (Load-sensing hydraulic system)
- Flow Rate
- 186 L/min
- System Pressure
- 22,1 MPa
- Hydraulic Tank
- 49 L
- Total Hydraulic System
- 78 L
Mobilitas
- Low Speed Travel
- 3,6 km/h
- High Speed Travel
- 10,8 km/h
- Gradeability
- 70 %
- Min Turning Radius
- —
Dimensi
- Length
- 5565 mm
- Width
- 3360 mm
- Height
- 3195 mm
- Ground Clearance
- 382 mm
- Track Width
- 1880 mm
- Tail Swing Radius
- —
Kapasitas Fluida
- Fuel Tank
- 345 L
- Engine Oil
- 16,5 L
- Coolant
- 48 L
- Hydraulic Tank
- 49 L
- Hydraulic System
- 78 L
- Transmission Oil
- 52 L
Fast Moving Spare Parts
- Engine Oil Filter
- 1R-1807
- Fuel Filter
- 1R-0751 (Advanced High Efficiency Main) / 326-1644 (Pre-filter dengan Water Separator)
- Air Filter (Outer)
- 256-7902
- Air Filter (Inner)
- 256-7903
- Hydraulic Return Filter
- 523-6902
- Hydraulic Pilot Filter
- 1R-0774
- Fan Belt
- 386-8152 / V-Ribbed Serpentine Belt
- Battery
- 2 x 12V / 1.000 CCA (Sistem kelistrikan elektrikal unit menggunakan heavy-duty 24V)
